L-FT PCB Tissue

L-FT PCB series Fiberglass tissue is mainly used as the basic material for the copper-cladded laminate of type CEM-3. It is with the uniform appearance, good conductivity, heat resistance, solvent resistance and compatible with epoxy resin. The specification of this production can meet the standard of IPC-4130. It is widely used for communication, radar and home electronics.

Main Features

1、 Uniformly dispersed fiber, high cleanliness

2、 Uniform thickness, good flatness, stable dimension

3、 Good heat resistance, keep its shape under high temperature

4、 Good solvent resistance

5、 Good compatibility with epoxy resin

Technical Specifications

Production code	Nominal Weight (g/m2)	Binder Content (%)	Longitudinal Breaking Tensile (N/50mm)	Transverse Breaking Tensile (N/50mm)	Longitudinal AcetoneImmersion Tensile (N/50mm)	Transverse Acetone Immersion Tensile (N/50mm)
L-FT -45	40±3	11±2	≥130	≥80	≥75	≥50
L-FT -50	50±3	11±2	≥175	≥100	≥75	≥50
L-FT -75	75±3	11±2	≥200	≥125	≥175	≥100
L-FT -105	105±5	11±2	≥225	≥150	≥200	≥125

Note: According to customer request, special specifications are also available.

L-FT PCB Tissue-[Data download].pdf|
